HGW HYDRAULICS

0403-12-12

3/4" Bore x 3/4" Male JIC

0403-12-12 is a 3/4" Bore x 3/4" Male JIC in the 0403 Series. For permanently joining a tube end (weld bore) to a male JIC line connection.

  • Steel
  • Unplated
  • Male Connector
$3.87
(0) Write a Review
SKU:
0403-12-12

Product Details

Connection A
TypeBore
Size3/4"
StandardNot Defined
Connection B
TypeMale JIC
Tube OD3/4"
StandardSAE J514 - Class 2A Thread
Thread Type1-1/16-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingUnplated
ShapeMale Connector
Weight0.19 lb
Cross References
Aeroquip73014-12S
Parker12 XHB3-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
