HGW HYDRAULICS

0403-16-12

1" Bore × 3/4" Male JIC 37° Flare · Straight Male Connector

The HGW 0403-16-12 is a straight male connector joining 1" bore to 3/4" male JIC 37° flare. Made from unplated-plated steel, it uses SAE J514 interfaces for compatible hydraulic applications.

  • Steel
  • Unplated
  • Male Connector
$7.86
(0) Write a Review
SKU:
0403-16-12

Product Details

Connection A
TypeBore
Size1"
StandardNot Defined
Connection B
TypeMale JIC 37° Flare
Tube OD3/4"
StandardSAE J514 · Class 2A Thread
Thread Type1-1/16-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingUnplated
ShapeMale Connector
Weight0.19 lb
Cross References
Aeroquip73014-16-12S
Parker12-16 XHB3-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
