HGW HYDRAULICS

0403-20-16-SS

1-1/4" Bore × 1" Male JIC 37° Flare · Straight Male Connector

The HGW 0403-20-16-SS is a straight male connector joining 1-1/4" bore to 1" male JIC 37° flare. Made from stainless steel, it uses SAE J514 interfaces for compatible hydraulic applications.

  • Stainless Steel
  • Male Connector
$326.96
(0) Write a Review
SKU:
0403-20-16-SS

Product Details

Connection A
TypeBore
Size1-1/4"
StandardNot Defined
Connection B
TypeMale JIC 37° Flare
Tube OD1"
StandardSAE J514 · Class 2A Thread
Thread Type1-5/16-12 UN
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeMale Connector
Weight0.50 lb
Cross References
Aeroquip259-73014-20-16
Parker16-20 XHB3-SS

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
