Google Merchant product image

HGW HYDRAULICS

0403-24-24

1-1/2" Bore x 1-1/2" Male JIC

0403-24-24 is a 1-1/2" Bore x 1-1/2" Male JIC in the 0403 Series. For permanently joining a tube end (weld bore) to a male JIC line connection.

  • Steel
  • Unplated
  • Male Connector
$9.37
(0) Write a Review
SKU:
0403-24-24

Product Details

Connection A
TypeBore
Size1-1/2"
StandardNot Defined
Connection B
TypeMale JIC
Tube OD1-1/2"
StandardSAE J514 - Class 2A Thread
Thread Type1-7/8-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingUnplated
ShapeMale Connector
Weight0.70 lb
Cross References
Aeroquip73014-24S
Parker24 XHB3-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
