HGW HYDRAULICS

1405-20-20-SS

1-1/4" Female NPTF x 1-1/4" Female NPSM Swivel

1405-20-20-SS is a 1-1/4" Female NPTF x 1-1/4" Female NPSM Swivel in the 1405 Series. For connecting pipe to an NPSM straight-thread using a swivel for alignment and without requiring pipe sealant.

  • Stainless Steel
  • Female Swivel Connector
  • None
$122.52
(0) Write a Review
SKU:
1405-20-20-SS

Product Details

Connection A
TypeFemale NPTF
Pipe Size1-1/4"
StandardSAE J476
Thread Type1-1/4-11-1/2 NPTF
Connection B
TypeFemale NPSM Swivel
Size1-1/4"
StandardSAE J514
Thread Type1-1/4-11-1/2 NPTF
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeFemale Swivel Connector
Weight0.92 lb
PlatingNone
Cross References
Aeroquip259-2046-20-20
Parker0207-20-20-SS
SAE Ref.SAE J514 20-20 140131S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
