1503-04-04-SS

1/4" Male NPTF 30° x 1/4" Female NPSM Swivel

1503-04-04-SS is a 1/4" Male NPTF 30° x 1/4" Female NPSM Swivel in the 1503-FG Series. For connecting pipe to an NPSM straight-thread at a 45° angle using a swivel for alignment and without requiring pipe sealant.

  • Stainless Steel
  • Male Swivel Elbow
  • None
$35.38
(0) Write a Review
SKU:
1503-04-04-SS

Product Details

Connection A
TypeMale NPTF 30°
Pipe Size1/4"
StandardSAE J476
Thread Type1/4-18 NPTF
Connection B
TypeFemale NPSM Swivel
Size1/4"
StandardSAE J514
Thread Type1/4-18 NPTF
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeMale Swivel Elbow
Weight0.11 lb
PlatingNone
Cross References
Aeroquip259-2049-4-4
Parker3107-4-4-SS
SAE Ref.SAE J514 4-4 140330S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
