1804-12-12-FG

3/4" Male JIC x 3/4" Split Flange Head

1804-12-12-FG is a 3/4" Male JIC x 3/4" Split Flange Head in the 1804-FG Series. For adapting 37° flared tubes or lines to an SAE Code 62 Flange port at a 90° angle using a forged body for additional strength.

  • Steel
  • Trivalent Zinc
$27.88
(0) Write a Review

Product Details

Connection A
TypeMale JIC
Tube OD3/4"
StandardSAE J514
Connection B
TypeSplit Flange Head
Size3/4"
StandardSAE J518
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
