1804-32-24-FG

2" Male JIC x 1-1/2" Split Flange Head

1804-32-24-FG is a 2" Male JIC x 1-1/2" Split Flange Head in the 1804-FG Series. For adapting 37° flared tubes or lines to an SAE Code 62 Flange port at a 90° angle using a forged body for additional strength.

  • Steel
  • Trivalent Zinc
$146.59
(0) Write a Review

Product Details

Connection A
TypeMale JIC
Tube OD2"
StandardSAE J514
Connection B
TypeSplit Flange Head
Size1-1/2"
StandardSAE J518
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
