HGW HYDRAULICS

2503-04-04-B

1/4" Male JIC x 1/4" Male NPTF 30°

2503-04-04-B is a 1/4" Male JIC x 1/4" Male NPTF 30° in the 2503-FG Series. For connecting 37° flared tubes or lines to pipe at a 45° angle without requiring pipe sealant on the JIC end.

  • Brass
  • Natural Finish
  • Male Elbow
$9.70
(0) Write a Review
SKU:
2503-04-04-B

Product Details

Connection A
TypeMale JIC
Tube OD1/4"
StandardSAE J514 - Class 2A Thread
Thread Type7/16-20 UNF
Connection B
TypeMale NPTF 30°
Pipe Size1/4"
StandardSAE J476
Thread Type7/16-20 UNF
Connection C
Connection D
Specifications
MaterialBrass
PlatingNatural Finish
ShapeMale Elbow
Weight0.07 lb
Cross References
Aeroquip2023-4-4B
Parker4-4 VTX-B
SAE Ref.SAE J514 4-4 070302B

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
