HGW HYDRAULICS

2504-06-06-SS

3/8" Male JIC x 3/8" Female NPTF 30°

2504-06-06-SS is a 3/8" Male JIC x 3/8" Female NPTF 30° in the 2504-FG Series. For connecting 37° flared tubes or lines to a male pipe thread at a 45° angle.

  • Stainless Steel
  • Union Elbow
  • None
$68.96
(0) Write a Review
SKU:
2504-06-06-SS

Product Details

Connection A
TypeMale JIC
Tube OD3/8"
StandardSAE J514 - Class 2A Thread
Thread Type9/16-18 UNF
Connection B
TypeFemale NPTF 30°
Pipe Size3/8"
StandardSAE J476
Thread Type9/16-18 UNF
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeUnion Elbow
Weight0.07 lb
PlatingNone
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
