HGW HYDRAULICS

2504-08-08-SS

1/2" Male JIC x 1/2" Female NPTF 30°

2504-08-08-SS is a 1/2" Male JIC x 1/2" Female NPTF 30° in the 2504-FG Series. For connecting 37° flared tubes or lines to a male pipe thread at a 45° angle.

  • Stainless Steel
  • Union Elbow
  • None
$59.76
(0) Write a Review
SKU:
2504-08-08-SS

Product Details

Connection A
TypeMale JIC
Tube OD1/2"
StandardSAE J514 - Class 2A Thread
Thread Type3/4-16 UNF
Connection B
TypeFemale NPTF 30°
Pipe Size1/2"
StandardSAE J476
Thread Type3/4-16 UNF
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeUnion Elbow
Weight0.16 lb
PlatingNone
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
