HGW HYDRAULICS

2504-24-24-FG

1-1/2" Male JIC x 1-1/2" Female NPTF 30°

2504-24-24-FG is a 1-1/2" Male JIC x 1-1/2" Female NPTF 30° in the 2504-FG Series. For connecting 37° flared tubes or lines to a male pipe thread at a 45° angle.

  • Steel
  • Trivalent Zinc
  • Union Elbow
$162.31
(0) Write a Review
SKU:
2504-24-24-FG

Product Details

Connection A
TypeMale JIC
Tube OD1-1/2"
StandardSAE J514 - Class 2A Thread
Thread Type1-7/8-12 UN
Connection B
TypeFemale NPTF 30°
Pipe Size1-1/2"
StandardSAE J476
Thread Type1-7/8-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeUnion Elbow
Weight1.41 lb
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
