2505-12-12-FG

3/4" Female JIC Swivel x 3/4" Male NPTF 30°

2505-12-12-FG is a 3/4" Female JIC Swivel x 3/4" Male NPTF 30° in the 2505-FG Series. For connecting a 37° flared tube or line to a male pipe thread at a 45° angle, with the female JIC swivel allowing the elbow to be tightened without.

  • Steel
  • Trivalent Zinc
  • Female Elbow
$21.00
(0) Write a Review
SKU:
2505-12-12-FG

Product Details

Connection A
TypeFemale JIC Swivel
Tube OD3/4"
StandardSAE J514 - Class 2B Thread
Thread Type1-1/16-12 UN
Connection B
TypeMale NPTF 30°
Pipe Size3/4"
StandardSAE J476
Thread Type1-1/16-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeFemale Elbow
Weight0.47 lb
Cross References
Aeroquip2044-12-12S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
