HGW HYDRAULICS

2601-04-04-04-B

1/4" Male JIC x 1/4" Male JIC x 1/4" Male NPTF 30°

2601-04-04-04-B is a 1/4" Male JIC x 1/4" Male JIC x 1/4" Male NPTF 30° in the 2601-FG Series. For branching pipe to two 37° flared tubes or lines without requiring pipe sealant.

  • Brass
  • Natural Finish
  • Male Branch Tee
$25.48
(0) Write a Review
SKU:
2601-04-04-04-B

Product Details

Connection A
TypeMale JIC
Tube OD1/4"
StandardSAE J514 - Class 2A Thread
Thread Type7/16-20 UNF
Connection B
TypeMale JIC
Tube OD1/4"
StandardSAE J514 - Class 2A Thread
Thread Type7/16-20 UNF
Connection C
TypeMale NPTF 30°
Pipe Size1/4"
StandardSAE J476
Thread Type7/16-20 UNF
Connection D
Specifications
MaterialBrass
PlatingNatural Finish
ShapeMale Branch Tee
Weight0.14 lb
Cross References
Aeroquip2030-4-4B
Parker4-4-4 STX-B
SAE Ref.SAE J514 4-4-4 070425B

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
