2605-04-04-04-B

1/4" Male JIC x 1/4" Male NPTF 30° x 1/4" Male JIC

2605-04-04-04-B is a 1/4" Male JIC x 1/4" Male NPTF 30° x 1/4" Male JIC in the 2605-FG Series. For connecting two 37° flared tubes or lines to pipe on the run without requiring pipe sealant.

  • Brass
  • Natural Finish
  • Male Run Tee
$14.59
(0) Write a Review
SKU:
2605-04-04-04-B

Product Details

Connection A
TypeMale JIC
Tube OD1/4"
StandardSAE J514 - Class 2A Thread
Thread Type7/16-20 UNF
Connection B
TypeMale NPTF 30°
Pipe Size1/4"
StandardSAE J476
Thread Type7/16-20 UNF
Connection C
TypeMale JIC
Tube OD1/4"
StandardSAE J514 - Class 2A Thread
Thread Type1/4-18 NPTF
Connection D
Specifications
MaterialBrass
PlatingNatural Finish
ShapeMale Run Tee
Weight0.14 lb
Cross References
Aeroquip2028-4-4B
Parker4-4-4 RTX-B
SAE Ref.SAE J514 4-4-4 070424B

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
