HGW HYDRAULICS

4601-10-10-NWO-B

5/8" Beaded Hose Barb × 7/8-14 Male Adjustable ORB · Male Adjustable Elbow

The HGW 4601-10-10-NWO-B is a male adjustable elbow joining 5/8" beaded hose barb to 7/8-14 male adjustable ORB. Made from brass, it uses SAE J1231-2 and SAE J1926 interfaces for compatible hydraulic applications.

  • Brass
  • Male Adjustable Elbow
$47.45
(0) Write a Review
SKU:
4601-10-10-NWO-B

Product Details

Connection A
TypeBeaded Hose Barb
Hose ID5/8"
StandardSAE J1231-2
Size5/8"
Connection B
TypeMale Adjustable ORB
Port Size7/8-14
StandardSAE J1926
Size7/8-14
Connection C
Connection D
Specifications
MaterialBrass
Weight4.41 lb
ShapeMale Adjustable Elbow
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
