HGW HYDRAULICS

4601-12-08-NWO-B

3/4" Beaded Hose Barb × 3/4-16 Male Adjustable ORB · Male Adjustable Elbow

The HGW 4601-12-08-NWO-B is a male adjustable elbow joining 3/4" beaded hose barb to 3/4-16 male adjustable ORB. Made from brass, it uses SAE J1231-2 and SAE J1926 interfaces for compatible hydraulic applications.

  • Brass
  • Male Adjustable Elbow
$54.42
(0) Write a Review
SKU:
4601-12-08-NWO-B

Product Details

Connection A
TypeBeaded Hose Barb
Hose ID3/4"
StandardSAE J1231-2
Size3/4"
Connection B
TypeMale Adjustable ORB
Port Size3/4-16
StandardSAE J1926
Thread Type3/4-16 UNF
Size3/4-16
Connection C
Connection D
Specifications
MaterialBrass
Weight0.26 lb
ShapeMale Adjustable Elbow
Cross References

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
