HGW HYDRAULICS

5406-16-02

1" Male NPTF × 1/8" Female NPTF · Reducer Bushing

The HGW 5406-16-02 is a reducer bushing joining 1" male NPTF to 1/8" female NPTF. Made from trivalent-zinc-plated steel, it uses SAE J476 interfaces for compatible hydraulic applications.

  • Steel
  • Trivalent Zinc
  • Reducer Bushing
$8.32
(0) Write a Review
SKU:
5406-16-02

Product Details

Connection A
TypeMale NPTF
Pipe Size1"
StandardSAE J476
Thread Type1-11-1/2 NPTF
Connection B
TypeFemale NPTF
Pipe Size1/8"
StandardSAE J476
Thread Type1-11-1/2 NPTF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeReducer Bushing
Weight0.49 lb
Cross References
Aeroquip2081-16-2S
Parker1 X 1/8 PTR-S
SAE Ref.SAE J514 16-2 140140C

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
