HGW HYDRAULICS

5406-20-16

1-1/4" Male NPTF x 1" Female NPTF

5406-20-16 is a 1-1/4" Male NPTF x 1" Female NPTF in the 5406 Series. For reducing or expanding between two pipe ends of different sizes without requiring pipe sealant.

  • Steel
  • Trivalent Zinc
  • Reducer Bushing
$5.98
(0) Write a Review

Product Details

Connection A
TypeMale NPTF
Pipe Size1-1/4"
StandardSAE J476
Thread Type1-1/4-11-1/2 NPTF
Connection B
TypeFemale NPTF
Pipe Size1"
StandardSAE J476
Thread Type1-1/4-11-1/2 NPTF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeReducer Bushing
Weight0.47 lb
Cross References
Aeroquip2081-20-16S
Parker1 1/4 X 1 PTR-S
SAE Ref.SAE J514 20-16 140140C

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
