5502-FG series product image

5502-12-12-B

3/4" Male NPTF 30° x 3/4" Female NPTF

5502-12-12-B is a 3/4" Male NPTF 30° x 3/4" Female NPTF in the 5502-FG Series. For joining two pipe ends at a 90° angle without requiring pipe sealant.

  • Brass
  • Natural Finish
  • Street Elbow
$26.87
(0) Write a Review
SKU:
5502-12-12-B

Product Details

Connection A
TypeMale NPTF 30°
Pipe Size3/4"
StandardSAE J476
Thread Type3/4-14 NPTF
Connection B
TypeFemale NPTF
Pipe Size3/4"
StandardSAE J476
Thread Type3/4-14 NPTF
Connection C
Connection D
Specifications
MaterialBrass
Weight0.61 lb
PlatingNatural Finish
ShapeStreet Elbow
Cross References
Aeroquip2089-12-12B
Parker3/4 CD-B
SAE Ref.SAE J514 12-12 140239B

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
