6401-32-32-O

2-1/2-12 Male ORB × 2" Male NPTF · Adapter Nipple

The HGW 6401-32-32-O is an adapter nipple joining 2-1/2-12 male ORB to 2" male NPTF. Made from trivalent-zinc-plated steel, it uses SAE J1926 and SAE J476 interfaces for compatible hydraulic applications.

  • Steel
  • Trivalent Zinc
  • Adapter Nipple
$68.98
(0) Write a Review
SKU:
6401-32-32-O

Product Details

Connection A
TypeMale ORB
Port Size2-1/2-12
StandardSAE J1926
Thread Type2-1/2-12 UN
Size2-1/2-12
Connection B
TypeMale NPTF
Pipe Size2"
StandardSAE J476
Thread Type2-1/2-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
Weight1.67 lb
ShapeAdapter Nipple
Cross References
AeroquipFF1796-3232S
Parker32-2 F5OF-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
