6405-03-04-O

3/8-24 Male ORB × 1/4" Female NPTF · Female Adapter

The HGW 6405-03-04-O is a female adapter joining 3/8-24 male ORB to 1/4" female NPTF. Made from trivalent-zinc-plated steel, it uses SAE J1926 and SAE J476 interfaces for compatible hydraulic applications.

  • Steel
  • Trivalent Zinc
  • Female Adapter
$10.34
(0) Write a Review
SKU:
6405-03-04-O

Product Details

Connection A
TypeMale ORB
Port Size3/8-24
StandardSAE J1926
Thread Type3/8-24 UNF
Size3/8-24
Connection B
TypeFemale NPTF
Pipe Size1/4"
StandardSAE J476
Thread Type3/8-24 UNF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
Weight0.10 lb
ShapeFemale Adapter
Cross References
Aeroquip2216-4-3S
Parker3-1/4 F5OG-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
