HGW HYDRAULICS

6425-08-08-SS

3/4-16 Female ORB × 3/4-16 Female ORB · Coupling

The HGW 6425-08-08-SS is a coupling joining 3/4-16 female ORB to 3/4-16 female ORB. Made from stainless steel, it uses SAE J1926 interfaces for compatible hydraulic applications.

  • Stainless Steel
  • Coupling
$31.91
(0) Write a Review
SKU:
6425-08-08-SS

Product Details

Connection A
TypeFemale ORB
Port Size3/4-16
StandardSAE J1926
Thread Type3/4-16 UNF
Size3/4-16
Connection B
TypeFemale ORB
Port Size3/4-16
StandardSAE J1926
Thread Type3/4-16 UNF
Size3/4-16
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeCoupling
Weight0.19 lb
Cross References
Parker8 G5HG5-SS

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
