HGW HYDRAULICS

6425-20-20-SS

1-5/8-12 Female ORB × 1-5/8-12 Female ORB · Coupling

The HGW 6425-20-20-SS is a coupling joining 1-5/8-12 female ORB to 1-5/8-12 female ORB. Made from stainless steel, it uses SAE J1926 interfaces for compatible hydraulic applications.

  • Stainless Steel
  • Coupling
$319.16
(0) Write a Review
SKU:
6425-20-20-SS

Product Details

Connection A
TypeFemale ORB
Port Size1-5/8-12
StandardSAE J1926
Thread Type1-5/8-12 UN
Size1-5/8-12
Connection B
TypeFemale ORB
Port Size1-5/8-12
StandardSAE J1926
Thread Type1-5/8-12 UN
Size1-5/8-12
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeCoupling
Weight0.88 lb
Cross References
Parker20 G5HG5-SS

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
