HGW HYDRAULICS

6502-32-32-SS

2" Male NPTF 30° x 2" Female JIC Swivel

6502-32-32-SS is a 2" Male NPTF 30° x 2" Female JIC Swivel in the 6502-FG Series. For connecting a pipe-threaded port to a 37° flared tube or line at a 45° angle, with the female swivel end allowing the elbow to be tightened without twisting.

  • Stainless Steel
  • Swivel Elbow
  • None
$2,266.83
(0) Write a Review

Product Details

Connection A
TypeMale NPTF 30°
Pipe Size2"
StandardSAE J476
Thread Type2-1/2-12 UN
Connection B
TypeFemale JIC Swivel
Tube OD2"
StandardSAE J514 - Class 2B Thread
Thread Type2-1/2-12 UN
Connection C
Connection D
Specifications
MaterialStainless Steel
ShapeSwivel Elbow
Weight3.45 lb
PlatingNone
Cross References
Aeroquip259-2070-32-32
Parker32 V6X-SS
SAE Ref.SAE J514 32-32 070321S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
