HGW HYDRAULICS

6602-12-16-12-FG

3/4" Male JIC x 1" Female JIC Swivel x 3/4" Male JIC

6602-12-16-12-FG is a 3/4" Male JIC x 1" Female JIC Swivel x 3/4" Male JIC in the 6602-FG Series. For connecting two 37° flared tubes or lines with a JIC line on the run using a swivel for alignment.

  • Steel
  • Trivalent Zinc
  • Swivel Run Tee
$106.36
(0) Write a Review
SKU:
6602-12-16-12-FG

Product Details

Connection A
TypeMale JIC
Tube OD3/4"
StandardSAE J514 - Class 2A Thread
Thread Type1-1/16-12 UN
Connection B
TypeFemale JIC Swivel
Tube OD1"
StandardSAE J514 - Class 2B Thread
Thread Type1-1/16-12 UN
Connection C
TypeMale JIC
Tube OD3/4"
StandardSAE J514 - Class 2A Thread
Thread Type1-5/16-12 UN
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeSwivel Run Tee
Weight0.99 lb
Cross References
Aeroquip203102-16-12-12S
Parker12-16-12 R6X-S
SAE Ref.SAE J514 12-16-12 070432C

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
