HGW HYDRAULICS

6802-24-32-NWO-FG

1-1/2" Male JIC x 2-1/2-12 Male Adjustable O-Ring Boss

6802-24-32-NWO-FG is a 1-1/2" Male JIC x 2-1/2-12 Male Adjustable O-Ring Boss in the 6802-NWO-FG Series. For connecting 37° flared tubes or lines to an O-ring boss port at a 45° angle.

  • Steel
  • Trivalent Zinc
  • Adjustable Elbow
$200.96
(0) Write a Review
SKU:
6802-24-32-NWO-FG

Product Details

Connection A
TypeMale JIC
Tube OD1-1/2"
StandardSAE J514 - Class 2A Thread
Thread Type1-7/8-12 UN
Connection B
TypeMale Adjustable O-Ring Boss
Port Size2-1/2-12
StandardSAE J1453 / J514
Thread Type1-7/8-12 UN
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeAdjustable Elbow
Weight2.73 lb
Cross References
Aeroquip2061-32-24S
Parker24-32 V5OX-S
SAE Ref.SAE J514 24-32 070320CN

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
