HGW HYDRAULICS

6902-10-06-NWO-FG

7/8-14 Male Adjustable ORB x 3/8" Female NPSM Swivel

6902-10-06-NWO-FG is a 7/8-14 Male Adjustable ORB x 3/8" Female NPSM Swivel in the 6902-NWO-FG Series. 6902-NWO-FG connects an SAE O-ring boss adjustable port to an NPSM straight-thread swivel in a 45-degree elbow.

  • Steel
  • Trivalent Zinc
  • Adjustable Swivel Elbow
$27.37
(0) Write a Review

Product Details

Connection A
TypeMale Adjustable ORB
Port Size7/8-14
StandardSAE J1926-3
Thread Type7/8-14 UNF
Connection B
TypeFemale NPSM Swivel
Size3/8"
StandardSAE J476
Thread Type7/8-14 UNF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeAdjustable Swivel Elbow
Weight0.32 lb
Cross References
Aeroquip2067-6-10S
Parker3507-10-6
SAE Ref.SAE J514 6-10 140357CN

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
