7040-04-02

1/4" Female NPTF x 1/8" Male BSPT 30°

7040-04-02 is a 1/4" Female NPTF x 1/8" Male BSPT 30° in the 7040 Series. SAE J476 Rigid Pipe Male BSPT Adapter.

  • Steel
  • Trivalent Zinc
  • Straight
$16.93
(0) Write a Review
SKU:
7040-04-02

Product Details

Connection A
TypeFemale NPTF
Pipe Size1/4"
StandardSAE J476
Thread Type1/4-18 NPTF
Connection B
TypeMale BSPT 30°
Pipe Size1/8"
StandardISO 7-1
Thread Type1/4-18 NPTF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
Weight0.09 lb
ShapeStraight
Cross References
Parker1/8X1/4F3HGS

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
