HGW HYDRAULICS

D2403-L18-L10-X

18mm Male DIN x 10mm Male DIN

D2403-L18-L10-X is a 18mm Male DIN x 10mm Male DIN in the D2403-REDUCER-X Series. For connecting two metric tubes or lines of different sizes, already containing nuts and cutting rings, or for connecting to a female DIN 2353 connector.

  • Steel
  • Zinc Nickel
  • Reducer Union
$20.51
(0) Write a Review

Product Details

Connection A
TypeMale DIN
Tube OD18mm
StandardDIN 2353, ISO 8434-1
Thread TypeM26X1.5
Connection B
TypeMale DIN
Tube OD10mm
StandardDIN 2353, ISO 8434-1
Thread TypeM26X1.5
Connection C
Connection D
Specifications
MaterialSteel
PlatingZinc Nickel
ShapeReducer Union
Weight0.13 lb
Cross References
ParkerGR18/10LCFX

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
