D2405-L06-04GP-SS-X

6mm Light Male DIN x 1/4" Female NPT Direct Gauge Port

D2405-L06-04GP-SS-X is a 6mm Light Male DIN x 1/4" Female NPT Direct Gauge Port in the D2405-GP-X Series. For connecting metric tube or line, already containing a nut and cutting ring, to a male NPT gauge.

  • Stainless Steel
  • Female Connector
  • None
$50.46
(0) Write a Review
SKU:
D2405-L06-04GP-SS-X

Product Details

Connection A
TypeMale DIN
Tube OD6mm Light
StandardDIN 2353 / ISO 8434-1
Thread TypeM12X1.5
Connection B
TypeFemale NPT Direct Gauge Port
StandardANSI/ASME B1.20.1
Port Size1/4"
Thread TypeM12X1.5
Connection C
Connection D
Specifications
MaterialStainless Steel
Weight1 lb
ShapeFemale Connector
PlatingNone
Cross References
ParkerMAV06L1/4NPTOMD71

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
