D2405-L35-20-SS

35mm DIN Tube x 1-1/4" Female NPT

D2405-L35-20-SS is a 35mm DIN Tube x 1-1/4" Female NPT in the D2405 Series. For connecting metric tube or line to a male NPT connector.

  • Stainless Steel
  • Female Connector
  • None
$591.74
(0) Write a Review
SKU:
D2405-L35-20-SS

Product Details

Connection A
TypeDIN Tube
Tube OD35mm
StandardDIN 2353 / ISO 8434-1
Thread TypeM45X2.0
Connection B
TypeFemale NPT
Pipe Size1-1/4"
StandardANSI/ASME B1.20.1
Thread TypeM45X2.0
Connection C
Connection D
Specifications
MaterialStainless Steel
Weight1.45 lb
ShapeFemale Connector
PlatingNone
Cross References
ParkerGAI35L11/4NPT71

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
