D6505-L18-08-SS

18mm Female Metric Swivel x 1/2" Male NPT

D6505-L18-08-SS is a 18mm Female Metric Swivel x 1/2" Male NPT in the D6505 Series. For connecting a male DIN 2353 connector to a female NPT connection.

  • Stainless Steel
  • Swivel Connector
  • None
$269.20
(0) Write a Review
SKU:
D6505-L18-08-SS

Product Details

Connection A
TypeFemale Metric Swivel
Size18mm
StandardDIN 2353 / ISO 8434-1
Thread TypeM26X1.5
Connection B
TypeMale NPT
Pipe Size1/2"
StandardANSI/ASME B1.20.1
Thread TypeM26X1.5
Connection C
Connection D
Specifications
MaterialStainless Steel
Weight0.50 lb
ShapeSwivel Connector
PlatingNone
Cross References
ParkerEGE18L1/2NPT71

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
