HGW HYDRAULICS

FS2603-08-08-10-FG

1/2" Male ORFS × 1/2" Male ORFS × 5/8" Male ORFS · Union Tee

The HGW FS2603-08-08-10-FG is a union tee combining 1/2" male ORFS, 1/2" male ORFS, and 5/8" male ORFS. Made from trivalent-zinc-plated steel, it uses SAE J1453 interfaces for compatible hydraulic applications.

  • Steel
  • Trivalent Zinc
  • Union Tee
$10.70
(0) Write a Review
SKU:
FS2603-08-08-10-FG

Product Details

Connection A
TypeMale ORFS
Tube OD1/2"
StandardSAE J1453 - Class 2A Thread
Thread Type13/16-16 UNF
Connection B
TypeMale ORFS
Tube OD1/2"
StandardSAE J1453 - Class 2A Thread
Thread Type13/16-16 UNF
Connection C
TypeMale ORFS
Tube OD5/8"
StandardSAE J1453 - Class 2A Thread
Thread Type13/16-16 UNF
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeUnion Tee
Weight0.56 lb
Cross References
AeroquipFF1898T0810S
Parker8-8-10 JLO-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
