HGW HYDRAULICS

FS6802-04-04-NWO-FG

1/4" Male ORFS x 7/16-20 Male Adjustable O-Ring Boss

FS6802-04-04-NWO-FG is a 1/4" Male ORFS x 7/16-20 Male Adjustable O-Ring Boss in the FS6802-NWO-FG Series. For connecting ORFS-sealed tubes or lines to an O-ring boss port at a 45° angle.

  • Steel
  • Trivalent Zinc
  • Adjustable Elbow
$3.68
(0) Write a Review

Product Details

Connection A
TypeMale ORFS
Tube OD1/4"
StandardSAE J1453 - O-Ring Face Seal
Thread Type9/16-18 UNF
Connection B
TypeMale Adjustable O-Ring Boss
Port Size7/16-20
StandardSAE J1453
Thread Type9/16-18 UNF
Connection C
Connection D
Specifications
MaterialSteel
PlatingTrivalent Zinc
ShapeAdjustable Elbow
Weight0.10 lb
Cross References
AeroquipFF2068T0404S
Parker4 V5OLO-S

Reference data is for selection and comparison. Actual system rating depends on mating components, assembly, media, temperature, and operating conditions.
